British Universal Beams-UB

British steel universal beam (UB) has narrow flange with parallel flange whose the depth of section always more than width of section, for example, UB 152 x 89 x 16, which means UB stand for universal beam and 152 stands for the depth of section is 152mm and 89 stands for width of section is 89mm and 16 stands for the weight is 16kg/ meters. British steel universal beam is one of structural steel section member which has good plasticity and toughness, strong ability against natural disasters, so was widely used in civil buildings, petroleum platforms and industrial buildings. Our factory can provide British standard (BS 4_1 2005) universal beam and hot dipped galvanized steel universal beam with British steel grade, such as S235JR, S235JO, S235J2, S275JR, S275JO S275J2, S355JR, S355JO, S355J2. If you want to know more detail about British steel universal beam, contact our sale, please.

British Universal Beams UB

Designation	Weight	d	b	t_w	t_f	r
Designation	kg/m	mm	mm	mm	mm	mm
UB 152 x 89 x 16	16	152.4	88.7	4.5	7.7	7.6
UB 203 x 102 x 23	23.1	203.2	101.8	5.4	9.3	7.6
UB 203 x 133 x 25	25.1	203.2	133.2	5.7	7.8	7.6
UB 203 x 133 x 30	30	206.8	133.9	6.4	9.6	7.6
UB 254 x 102 x 22	28	254	101.6	5.7	6.8	7.6
UB 254 x 102 x 25	32	257.2	101.9	6	8.4	7.6
UB 254 x 102 x 28	36.1	260.4	102.2	6.3	10	7.6
UB 254 x 146 x 31	31.1	251.4	146.1	6	8.6	7.6
UB 254 x 146 x 37	37	256	146.4	6.3	10.9	7.6
UB 254 x 146 x 43	43	259.6	147.3	7.2	12.7	7.6
UB 305 x 102 x 25	31.6	305.1	101.6	5.8	7	7.6
UB 305 x 102 x 28	35.9	308.7	101.8	6	8.8	7.6
UB 305 x 102 x 33	41.8	312.7	102.4	6.6	10.8	7.6
UB 305 x 165 x 40	40.3	303.4	165	6	10.2	8.9
UB 305 x 165 x 46	46.1	306.6	165.7	6.7	11.8	8.9
UB 305 x 165 x 54	54	310.4	166.9	7.9	13.7	8.9
UB 356 x 127 x 33	42.1	349	125.4	6	8.5	10.2
UB 356 x 127 x 39	49.8	353.4	126	6.6	10.7	10.2
UB 356 x 171 x 45	57.3	351.4	171.1	7	9.7	10.2
UB 356 x 171 x 51	64.9	355	171.5	7.4	11.5	10.2
UB 356 x 171 x 57	72.6	358	172.2	8.1	13	10.2
UB 356 x 171 x 67	85.5	363.4	173.2	9.1	15.7	10.2
UB 406 x 140 x 39	49.7	398	141.8	6.4	8.6	10.2
UB 406 x 140 x 46	58.6	403.2	142.2	6.8	11.2	10.2
UB 406 x 178 x 54	69	402.6	177.7	7.7	10.9	10.2
UB 406 x 178 x 60	76.5	406.4	177.9	7.9	12.8	10.2
UB 406 x 178 x 67	85.5	409.4	178.8	8.8	14.3	10.2
UB 406 x 178 x 74	94.5	412.8	179.5	9.5	16	10.2
UB 457 x 152 x 52	66.6	449.8	152.4	7.6	10.9	10.2
UB 457 x 152 x 60	76.2	454.6	152.9	8.1	13.3	10.2
UB 457 x 152 x 67	85.6	458	153.8	9	15	10.2
UB 457 x 152 x 74	94.5	462	154.4	9.6	17	10.2
UB 457 x 152 x 82	105	465.8	155.3	10.5	18.9	10.2
UB 457 x 191 x 67	85.5	453.4	189.9	8.5	12.7	10.2
UB 457 x 191 x 74	94.6	457	190.4	9	14.5	10.2
UB 457 x 191 x 82	104	460	191.3	9.9	16	10.2
UB 457 x 191 x 89	114	463.4	191.9	10.5	17.7	10.2
UB 457 x 191 x 98	125	467.2	192.8	11.4	19.6	10.2
UB 533 x 210 x 101	129	536.7	210	10.8	17.4	12.7
UB 533 x 210 x 109	139	539.5	210.8	11.6	18.8	12.7
UB 533 x 210 x 122	155	544.5	211.9	12.7	21.3	12.7
UB 533 x 210 x 82	105	528.3	208.8	9.6	13.2	12.7
UB 533 x 210 x 92	117	533.1	209.3	10.1	15.6	12.7
UB 610 x 229 x 101	129	602.6	227.6	10.5	14.8	12.7
UB 610 x 229 x 113	144	607.6	228.2	11.1	17.3	12.7
UB 610 x 229 x 125	159	612.2	229	11.9	19.6	12.7
UB 610 x 229 x 140	178	617.2	230.2	13.1	22.1	12.7
UB 610 x 305 x 149	149.2	612.4	304.8	11.8	19.7	16.5
UB 610 x 305 x 179	179	620.2	307.1	14.1	23.6	16.5
UB 610 x 305 x 238	238.1	635.8	311.4	18.4	31.4	16.5
UB 686 x 254 x 125	159	677.9	253	11.7	16.2	15.2
UB 686 x 254 x 140	178	683.5	253.7	12.4	19	15.2
UB 686 x 254 x 152	194	687.5	254.5	13.2	21	15.2
UB 686 x 254 x 170	217	692.9	255.8	14.5	23.7	15.2
